LilyGO T-Deck Complete Mesh Node with GPS, Antenna, and Battery
The All-in-One, Ready-to-Run T-Deck Communicator
Forget sourcing parts, complex soldering, and flashing firmware. This is a complete, professionally assembled T-Deck communicator. We've done all the work so you can get on the network right out of the box.
It arrives fully assembled, pre-flashed with your choice of the latest Meshtastic or MeshCore firmware, and ready for your next adventure. Just pick your preferred platform at checkout. It's the simplest way to get a powerful, GPS-enabled Mesh node.
Key Features
- Professionally Assembled & Ready to Use: No setup required. Just turn it on and connect.
- Powerful M100 GPS, Securely Soldered: Enjoy reliable, high-performance GPS tracking without worrying about loose connections.
- Your Choice of Case: Available in the Field-Ready Case or the Standard (V2) Alley Cat case, both keep your investment safe in the field.
- High-Gain Gizont Antenna: Includes a powerful 915MHz antenna and SMA adapter for excellent range.
- Long-Life LiPo Battery: Comes with a high-quality 8000mAh MakerNova battery for extended use, the same battery in every case style.
Step One: Choose Your Case Style
Both styles ship with the same 8000mAh battery, GPS module, and antenna, so pick whichever build fits how you carry it.
- Field-Ready Case: Our most rugged option, built for demanding outdoor use.
- Standard (V2) Alley Cat Case: The classic Alley Cat design, in the Standard (V2) size.
Choose Your Firmware, Flashed Free at Checkout
- Meshtastic (Default): The most popular open-source mesh networking firmware. Features an updated touchscreen UI, long-range LoRa messaging, GPS tracking, and a large active community. No phone required for basic use.
- MeshCore (Mesh OS): A lightweight alternative mesh networking OS built for the T-Deck's keyboard-first form factor. Great for users who want a terminal-style experience and more direct control.
What's In The Box
- 1x Fully Assembled T-Deck in Your Selected Case Style
- 1x M100 Mini GPS (Soldered and Installed)
- 1x Gizont 915MHz Antenna & SMA Adapter
- 1x MakerNova LiPo Battery (8000mAh)
- Pre-Flashed with the latest [Selected] Firmware
▸ Full Technical Specifications
T-Deck Specifications
- MCU: ESP32-S3FN16R8 Dual-core LX7
- Connectivity: 2.4 GHz Wi-Fi + Bluetooth 5 (LE)
- Flash: 16MB
- PSRAM: 8MB
- Display: 2.8" ST7789 IPS LCD (320x240)
- Onboard: Trackball, Microphone, Speaker
Gizont Antenna Specs
- Frequency: 915MHz
- Gain: 10 dBi
- SWR: ≤ 1.5
M100 Mini GPS Specs
- Frequency Bands: GPS L1, GLONASS L1, BDS B1, GALILEO E1, SBAS L1, OZSS L1
- Channels: 72ch
- Baud Rate: 115200bps
Meshtastic® is a registered trademark of Meshtastic LLC. MeshCore is an open-source mesh networking project released under the MIT License, and its name is currently the subject of an unresolved trademark dispute; it is used here only to describe firmware compatibility. Software components referenced in this listing are released under their respective open-source licenses, see GitHub for details. No warranty is provided, use at your own risk.
